PPR / ABS Hdpe Pipe Production Line , 3 - 10 Kg/H Plastic Pipe Production Line

Chiny PPR / ABS Hdpe Pipe Production Line , 3 - 10 Kg/H Plastic Pipe Production Line dostawca

Duży Obraz :  PPR / ABS Hdpe Pipe Production Line , 3 - 10 Kg/H Plastic Pipe Production Line

Szczegóły Produktu:

Place of Origin: ZHANGJIAGANG
Nazwa handlowa: LB
Orzecznictwo: CE / ISO
Model Number: LB

Zapłata:

Minimum Order Quantity: 1 SET
Cena: negotiation
Packaging Details: NORMAL PACKAGE
Delivery Time: 45 WORKING DAYS
Payment Terms: L/C, T/T,
Supply Ability: 15 SETS PER MONTH
Contact Now
Szczegółowy opis produktu
Voltage: 380V/220V Condition: New
COLOUR: BLACK, ORANGE outlet: single outlet
Output: 3-10 kg/h Inverte: ABB

Plastic PE Pipe Extrusion Line For PPR , ABS / Single Screw Extruders



The Single Screw Extruder is designed for the PE and PP pipe applications.

We target to provide the optimal solutions for the customer’s special needs with the advantage of flexibility in material choices, high performance and long durability.

High flexibility in raw material combinations

Gentle and homogeneous plastification

Different screw geometries for customer’s special needs

Barrel with air cooling system

AC motors for low energy consumption

Control panel with color touch screen

Product Range

Screw diameters from to 45 to 160 mm

L/D ratios from 30:1 to 36:1

Outputs from 85 to 1650 kg/h

All Extrusion pipe lines can be equipped with various auxiliary equipments in order to meet our customer’s requests and provide solution from a single source.



Covering a large range of diameters, we supply vacuum calibration sleeves which are used inside the vacuum tanks for the calibration process.

Features

High wear resistant

Definite outer diameter calibration

Product Range Diameters from 16 to 800 mm








Application:

This machine is mainly used to process PP,PE,PPR and other plastic materials equipped with auxiliary machines, it can manufacture profile, pipes , wire and other plastic products and granulation. it has the advantage of simple production technological process, high output,stable quality and low cost.




Features:


SJ series extruder is composed of barrel screw,gear transmission system,measurabe feeding, vacuum gasing, heating, cooling and electronic cotrol components etc.
The screw is made by high precision special digital screw miller, extruding property can be highly harmonized.
It has firstly introduced advanced technique of producing screws with variable pitch and depth, so that the material can be more softly sheared and cut.
The distribution box is specially designed, pull force bearing is fully imported, the drive life span can be prolonged. It can bear larger extruding pressure.
The involute gear driving is characterized by low noise,stable in working ,big bearing capacity and long service life.
This machine is advanced in design,high in output,good in plasticization and low in energy consumption.



Technical Data:



Product Name Screw diameter (mm) L/D Motor power
kW
Screw speed
(r/min)
Max output
(kg/h)
SJ25/25 25 25:1 1.5 100 3.4
SJ30/25 30 25:1 5.5 125 12.5
SJ45/25 45 25:1 7.5 100 20
SJ45/30 45 30:1 15 145 40
SJ45/30 45 30:1 30 185 120
SJ65/25 65 25:1 22 100 60
SJ65/30 65 30:1 30 105 80
SJ65/30 65 30:1 45 120 120
SJ75/30 75 30:1 90 120 350
SJ90/25 90 25:1 55 120 150
SJ90/30 90 30:1 90 94 250
SJ120/25 120 25:1 90 94 350
SJ120/30 120 30:1 110 94 350
SJ120/33 120 33:1 250 94 800
SJ150/30 150 30:1 132 50 350



Our Advantages:

 High quality
 Reliable, Durable
 Reasonable and competitive price
 Good after-sale service & within 12hours replying by email
 One year guarantee


Our Services:


Engineers available to service machinery overseas.
Warranty: One year after B/L date.
If the equipment fails due to the quality of the machine during one year, we will provide replacement and the repair Free of Charge. After One Year customer must pay for Spare Parts, we will provide long-term technical assistance.

Workers must operate the machines according to the design of the machine. XINYAO Machinery will not be responsible for accidents which are caused by improper operation of workers.
