Heat Resistant Plastic Recycling Line Smart PLC Control System Easy Operation

Orzecznictwo
dobra jakość Linia do wytłaczania rur PE na sprzedaż
dobra jakość Linia do wytłaczania rur PE na sprzedaż
Im Online Czat teraz

Heat Resistant Plastic Recycling Line Smart PLC Control System Easy Operation

Chiny Heat Resistant Plastic Recycling Line Smart PLC Control System Easy Operation dostawca
Heat Resistant Plastic Recycling Line Smart PLC Control System Easy Operation dostawca Heat Resistant Plastic Recycling Line Smart PLC Control System Easy Operation dostawca

Duży Obraz :  Heat Resistant Plastic Recycling Line Smart PLC Control System Easy Operation

Szczegóły Produktu:

Place of Origin: ZHANGJIAGANG
Nazwa handlowa: LB
Orzecznictwo: CE, ISO
Model Number: LB

Zapłata:

Minimum Order Quantity: 1 SET
Cena: USD, EUR
Packaging Details: STANDARD PACKAGE
Delivery Time: 60 WORKING DAYS
Payment Terms: L/C, T/T
Supply Ability: 10 SETS PER MONTH
Contact Now
Szczegółowy opis produktu
RAW MATERIAL: PP/PE RIGID & FILM WASTES Voltage: WANROOETECH
OPERATION: AUTOMATIC Function: Crushing, Washing, Drying And Granulating
Warranty: 1year Production Capacity: 100-3000kg/h

Plastic Recycling Plant/Plastic recycling machine/PP PE Washing Line



Product Description:



The PET bottle recycling plant takes dirty bottles and transforms them into clean PET flakes. This is an export commodity which can be sold and used for many creative applications. And the flakes can be further processed and reutilized with high commercial value. The production capacity we can make on the PET Bottle washing and recycling line can be 100kg to 3000kg per hour.



Features:



1. Coordinating the production line with follow programmed work (granulating system), and it will make waste and dirty PET bottles to be the PET granule material and in order to producing new PET bottles.

2. Friendly control system (PLC integrated & separated control on each machine) and touch screen panel, easy for operation, monitor and emergency stop.

3. All parts contacting with plastic material and water are made of high-quality 304 and touch screen panel, easy for operation, monitor and emergency stop.

4. The whole production line can be designed on the basis of how dirty the flakes are, and make sure of the quality of the final products.



System Configuration:



No. Machine Name Note
1 Bale breaker Custom
2 Belt Conveyor PVC Belt
3 Metal detector Custom
4 Label Remover Remove the label from the bottles.
5 Manual Sorting Belt Custom,PVC Belt
6 Belt Conveyor PVC Belt
7 Crusher Blade metal:alloy(9CrSi or SKD-II)
8 Screw Loader Made of Stainless steel
9 Hot Washer Made of Stainless steel ,can put some soda
10 High-speed Friction Washer

Made of Stainless steel

Can be design Two-screw

11 Sink-Float Tank Single-screw or Two-screw
12 Dewatering Machine Vertical or Horizontal
13 Drying system Made of Stainless steel
14 Storage hopper Normally 1000L
15 Flakes Pneumatic Separating Machine New style label remover for flakes
16 Electrical Control Cabinet

Siemens DELIXI

Schneider ABB





Technical Parameters



Model Material Install Power Capacity Water Consumption End Products Humidity
PNQX-PET300 PET,PS,PC,ABS 100kw 300kg/h 4-6litres/kg <=3%
PNQX-PET500 PET,PS,PC,ABS 150kw 500kg/h 3-6litres/kg <=3%
PNQX-PET800 PET,PS,PC,ABS 200kw 800kg/h 3-5litres/kg <=3%
PNQX-PET1000 PET,PS,PC,ABS 280kw 1,000kg/h 2-3litres/kg <=3%
PNQX-PET1500 PET,PS,PC,ABS 350kw 1.5Tons 2-3litres/kg <=3%
PNQX-PET2000 PET,PS,PC,ABS 400kw 2Tons 2-3litres/kg <=3%
PNQX-PET3000 PET,PS,PC,ABS 500kw 3Tons 2-3litres/kg <=3%
