1180mm Profile Size PVC Cable Trunk Making Machine With 8m Calibration Table and 55/110 Conical Twin Screw Extruder

1 zestaw
MOQ
USD,EUR
Cena £
1180mm Profile Size PVC Cable Trunk Making Machine With 8m Calibration Table and 55/110 Conical Twin Screw Extruder
cechy Galeria opis produktu Oceny i recenzje Poprosić o wycenę
cechy
specyfikacje
Typ wytłaczarki: 55/110 stożkowa wytłaczarka bliźniaczy
Rozmiar profilu: 1180 mm
Moc silnika: 22kW
Surowiec: PVC proszek i dodatki
Off-off: Dwa niezależne utwory
Tabela kalibracji: Osiem mersów długości
Metoda pakowania: Drewniane pudełko i pakiet filmowy
Rozmiar profilu: Według rysunku klientów
Czas dostawy: W ciągu 90 dni
Podkreślić:

1180mm Profile Size PVC Cable Trunk Making Machine

,

8m Calibration Table PVC Profile Extrusion Line

,

55/110 Conical Twin Screw Extruder PVC Profile Production Line
Podstawowe informacje
Miejsce pochodzenia: Zhangjiagang
Nazwa handlowa: LB
Orzecznictwo: CE,ISO9001
Numer modelu: LB-1180
Zapłata
Szczegóły pakowania: Pakiet Standardowy
Czas dostawy: 45 dni roboczych
Zasady płatności: L/C, T/T
Możliwość Supply: 15 zestawów miesięcznie
opis produktu
1180mm Profile Size PVC Cable Trunk Making Machine With 8m Calibration Table
PVC Profile Making Machinery
This plastic PVC profile cable trunk production line is engineered for manufacturing various PVC profiles including window and door profiles, ceiling panels, and cable trunking systems. Custom solutions and molds are developed based on specific profile drawings.
Production Process
The complete manufacturing workflow includes: PVC powder + additives → mixing → material feeding → twin screw extrusion → molding and calibration → vacuum forming → haul-off → cutting → discharge racking.
Key Features
  • Conical twin screw extruder compatible with both PVC powder and granules
  • Integrated degassing system for superior material plasticization
  • High-speed mold technology for enhanced productivity
  • Comprehensive PLC control system for centralized operation
Technical Specifications
Model LB180 LB240 LB300 LB600
Max Product Width (mm) 180 240 300 600
Screw Model SJ55/110 SJ65/132 SJ65/132 SJ80/156
Motor Power 22KW 37KW 37KW 55KW
Cooling Water (m³/h) 5 7 7 10
Compressor (m³/h) 0.2 0.3 0.3 0.4
Total Length (m) 18 22 22 25
Conical Twin Screw Extruder
Engineered specifically for processing dry PVC powder blends, our conical twin screw extruder ensures homogeneous mixing, superior plastification, and optimal conveying efficiency. The permanent magnet synchronous motor delivers high energy efficiency, while the integrated PLC system enables centralized control of the entire production line.
Plate Mould System
Features double-strand mold technology for PVC trunking production, significantly increasing output capacity. Advanced channel design provides exceptional flow performance, and precision manufacturing guarantees high-accuracy profile production.
Calibration Table
Constructed with a robust steel frame and SUS 304 stainless steel body, the calibration table incorporates multi-dimensional position adjustment. Strategic placement of water pumps and vacuum calibrators ensures rapid shaping and cooling of PVC profiles, with sufficient length for complete profile formation.
Haul-off & Cutting System
Even force distribution across caterpillar tracks delivers consistent hauling power. High-quality rubber components ensure reliable performance, while pneumatic pressure systems facilitate easy adjustment and product protection. Customizable cutting options include swarf-free and saw cutting methods.
1180mm Profile Size PVC Cable Trunk Making Machine With 8m Calibration Table and 55/110 Conical Twin Screw Extruder 0 1180mm Profile Size PVC Cable Trunk Making Machine With 8m Calibration Table and 55/110 Conical Twin Screw Extruder 1 1180mm Profile Size PVC Cable Trunk Making Machine With 8m Calibration Table and 55/110 Conical Twin Screw Extruder 2 1180mm Profile Size PVC Cable Trunk Making Machine With 8m Calibration Table and 55/110 Conical Twin Screw Extruder 3
